Used Wood Grabbing Machine, Four-Wheel Drive Wood Transfer 20t Truck Mounted Crane
| Place of Origin | CHINA |
|---|---|
| Certification | ISO9001 |
| Minimum Order Quantity | 1 |
| Price | US $38,888 / Piece |
| Packaging Details | Nuked |
| Delivery Time | 15 working days |
| Payment Terms | T/T,LC, |
| Supply Ability | 150 sets/month |
Product Details
| Model NO. | CLW | Condition | New |
|---|---|---|---|
| Maximum Lifting Height | 10-15m | Maximum Lifting Weight | 14-16t |
| Shaft Number | 3 | Crane Jib | Five-Arm |
| Type | Folding | Transport Package | Whole Vehicle Transportation |
| Specification | 18T | Trademark | CLW |
| Origin | Suizhou | Production Capacity | 680 Vehicles /Year |
Product Description
Dongfeng D7V front four rear eight grab bucket garbage truck
Vehicle size: 12000X2550X3950
Cargo box size: 7880X2400X1500
Total weight: 31000KG
Curb weight: 21000KG
Chassis configuration
D7V new cab, Yuchai YCK08350-60, wheelbase 2150+4250+1350, Shaanxi Gear 12 speed (12JS160) gearbox, 5T dual front axle, 10 ton dual rear axle, tires 11.00R20, main beam 300 straight through three layers, with original ABS, electric glass, lower protection, airbag seats, central locking, LED headlights, four point suspension, original air conditioning, driving recorder, with special power take-off for on-board crane and remote throttle, with new regulations
Installation Configuration
Cheng Li is equipped with a 12 ton 5-section folding arm and a maximum working arm length of 12 meters and a maximum working height of 14 meters. It is equipped with an electronic control one control three operation valve, a excavator like operating handle, and comes with a hydraulic radiator as standard. The entire crane and gripper can rotate 360 ° infinitely. The gripper type can be selected according to the actual working conditions, with 3+2 gripper or 4 flap gripper. It has strong gripping ability and fast loading speed. All hydraulic components of the whole machine are made of pure imported or domestic first-line brands, with low failure rate and good after-sales service. Cheng Li accompanies the driver and the driver to safeguard your wealth road!
[Cargo box configuration]
Side 3, bottom 5, front single roof dump truck, reinforced cargo compartment horizontal lining, front and rear balance beams, four flip seats.
Vehicle size: 12000X2550X3950
Cargo box size: 7880X2400X1500
Total weight: 31000KG
Curb weight: 21000KG
Chassis configuration
D7V new cab, Yuchai YCK08350-60, wheelbase 2150+4250+1350, Shaanxi Gear 12 speed (12JS160) gearbox, 5T dual front axle, 10 ton dual rear axle, tires 11.00R20, main beam 300 straight through three layers, with original ABS, electric glass, lower protection, airbag seats, central locking, LED headlights, four point suspension, original air conditioning, driving recorder, with special power take-off for on-board crane and remote throttle, with new regulations
Installation Configuration
Cheng Li is equipped with a 12 ton 5-section folding arm and a maximum working arm length of 12 meters and a maximum working height of 14 meters. It is equipped with an electronic control one control three operation valve, a excavator like operating handle, and comes with a hydraulic radiator as standard. The entire crane and gripper can rotate 360 ° infinitely. The gripper type can be selected according to the actual working conditions, with 3+2 gripper or 4 flap gripper. It has strong gripping ability and fast loading speed. All hydraulic components of the whole machine are made of pure imported or domestic first-line brands, with low failure rate and good after-sales service. Cheng Li accompanies the driver and the driver to safeguard your wealth road!
[Cargo box configuration]
Side 3, bottom 5, front single roof dump truck, reinforced cargo compartment horizontal lining, front and rear balance beams, four flip seats.
