Heavy-Duty HOWO 8X4 Sewage Suction Truck for Efficient Waste Management
| Place of Origin | CHINA |
|---|---|
| Certification | ISO9001 |
| Minimum Order Quantity | 1 |
| Price | US $36,500-39,500 |
| Packaging Details | Nuked |
| Delivery Time | 15 working days |
| Payment Terms | T/T,LC, |
| Supply Ability | 150 sets/month |
Product Details
| Model NO. | CLW5310QXD5 | Emission Standard | Euro 3 |
|---|---|---|---|
| Payload | 30T | Transmission Type | Manual |
| Fuel | Diesel | Drive Wheel | 8X4 |
| Condition | New | Tire Specifications | 11.00r20 |
| Steering Wheel Type | Hydraulic Power Assistance | Steel Plate Material | Q345manganese Steel |
| Transport Package | Complete Vehicle Transportation | Specification | 12000X2550X3950mm |
| Trademark | CLW | Origin | Hubei, China |
| HS Code | 8701909000 | Production Capacity | 1000-10000 |
Product Description
The suction truck is a special vehicle composed of suction pump, suction tank, suction pipe and other facilities, which is composed of tank and suction pump. The main function of the suction truck series produced by our company is to suck and transport feces, silt, stones and other liquid mixed with large suspended debris. It is especially suitable for dredging, suction, shipping and discharging, especially the stones, bricks and other larger objects in the sewer and dredge any blocked sewer. There are two ways of discharge: pressurized discharge and autocurrent discharge. The suction car has the characteristics of high suction efficiency, self-priming, self-drainage and direct irrigation, and has fast and simple operation. Suitable for large, medium, small and small sanitation, municipal departments use.
Introduction to the main parts of the vehicle:
| Accessories name | model | brand |
| panel | Q345-A carbon steel standard board | Wuhan Iron & Steel Co., Ltd |
| vacuum pump | Weilong | Hangzhou Weilong Pump Industry Co., LTD |
| power takeoff | power takeoff | Hubei Dacheng Gear Co., LTD |
| hydro-cylinder | 800/1200mm | Hengli Auto Parts Co., Ltd |
| multiple unit valve | The DL-8 series | Yangzhou Jiangyan Hydraulic Parts Co., LTD |
| Note: Install two 8-meter suction pipes, two sets of Yin and Yang ends, filter screen, dung guide pipe at the inlet, 10-15 cm at the bottom of the tank, and 4 locking devices on the back cover. | ||
| order number | Content (corresponding to the real car picture) |
| 1 | The effective volume of the sewage tank is about 25square meters, and the shape design of the tank and the water tank is coordinated and beautiful. The whole vehicle color is optional. |
| 2 | The tank is cylindrical, butterfly head, formed with special mold, the back cover is hydraulically opened with manual locking. The sealing ring of the back cover is resistant to sewage corrosion. After the sealing ring is embedded in the sealing groove, it is close with the sealing groove without clearance. |
| 3 | The head adopts 6mm high quality carbon steel plate, the cylinder adopts 6mm thick high quality carbon steel plate, the material is Q235B, and the negative thickness deviation meets the corresponding national standard. In order to prevent the negative pressure deformation of the tank and the seal head, the tank and the inner head are strengthened. |
| 4 | The wave plate in the tank is fortified, the steel plate thickness is 4mm, the wave plate is firmly connected with the tank, and there is no obvious slag clamp and pores at the connection. The upper part of the wave plate is vent, and the lower flow port can pass. |
| 5 | The tank flange has the same diameter of the outer circle as the rear head flange. Control the flange deformation after welding with the cylinder to ensure the sealing ring. The sewage connection tank is allowed to weld in the lower half of the cylinder flange. |
| 6 | The suction pipe and drainage pipe are all made of seamless steel pipe, and the wall thickness is not less than 4mm. The suction pipe and drainage pipe are stuck. The sewage pipe are aluminum alloy ball valve, and the valve is marked by the rear opening. And the rear drainage pipe is 5 to 10 degrees below the horizontal face; the rear drainage port and the rear protection shall not interfere. |
| 7 | The suction tank can pressure dump, also can lift dump. When unloading, the tank rises and drops smoothly, without any movement, collision and lag phenomenon. |
| 8 | An overflow prevention device shall be installed at the upper pumping outlet of the tank. |
| 9 | Cylindrical transparent window fits the front head of the tank for operator observation. Install the liquid level alarm device to the tank body. |
| 10 | U-shaped bolts are used to connect the subframe and the main car girder, and the thread should expose the nut 3~5 buckle after installation. |
FAQ
Q1: Are you manufacturer or trading company?
A: We are direct manufacturer with more than 20years' experience.
Q2: What is the lead time?
A: Normally it will take 20-45 working days after getting down payment.
Q3: How should I pay for you if I place order to you?
A: We prefer T/T, 30%-50% as deposit, balance before shipment, L/C is also acceptable and negotiable.
Q4: If I do not like the color, could I change the color?
A: Yes, most of our trucks have standard colors, if all colors could not meet your needs; we could customize by your request.
Q5: Can you supply the spare parts of this truck?
A: Yes, We can supply the spare parts for all the trucks we selling. We have spare parts department professional for this. Once you need spare parts we can supply immediately.
Q6: Do you have oversea service?
A: When you have some problems which you cannot solve, we will arrange our engineers to your country to help you.
Q7: How about your product quality?
A: All our spare parts are from the original manufacturers, the quality is 100% guaranteed.
Flexible Payment Terms for Different Trucks and Business Besides traditional payment terms such as TT, LC, we still offer our stable and long-term partners with various financial support and credit payment terms at different periods. Excellent and Outstanding After Sales Service Our professional technicians and mechanics and parts staff always concentrate all our products and our customers. Top Starting Point, High Quality and Worry-free Service is our promise to all our customers.
